Kamera Sensorius 1/3" Progressive Scan CMOS Maks. rezoliucija 2560 × 1440 Min. apšvietimas Color: 0.001 Lux @ (F1.0, AGC ON),0 Lux with light Užrakto greitis 1/3 s to 1/100,000 s Day & Night IR cut filter Kampo keitimas Pan: 0° to 355°,tilt: 0° to 180°,rotate: 0° to 355° Lęšis Lęšio tipas Fixed focal lens, 2.8 and 4 mm optional Focal Length & FOV 2.8 mm, horizontal FOV 115°, vertical FOV 60°, diagonal FOV 143°
4 mm, horizontal FOV 94°, vertical FOV 50°, diagonal FOV 110°
Lęšio montavimas M12 Rainelės tipas Fixed Diafragama F1.0 DORI DORI 2.8 mm, D: 64 m, O: 25 m, R: 12 m, I: 6 m
4 mm, D: 77 m, O: 30 m, R: 15 m, I: 7 m
Apšvietimas Papildomo apšviešimo tipas IR,White Light Papildomo apšvietimo diapazonas Up to 50 m Išmanus papildomas apšvietimas Yes IR bangos ilgis 850 nm Vaizdas Pagrindinis srautas 50 Hz:
20 fps (2560 × 1440)
25 fps (1920 × 1080, 1280 × 720)
60 Hz:
20 fps (2560 × 1440)
24 fps (1920 × 1080, 1280 × 720)
Antrinis srautas 50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 24 fps (1280 × 720, 640 × 480, 640 × 360)
Vaizdo suspaudimas Main stream: H.265+/H.265/H.264+/H.264,
Sub-stream: H.265/H.264/MJPEG
Vaizdo bitų greitis 32 Kbps to 8 Mbps H.264 tipas Baseline Profile,Main Profile,High Profile H.265 tipas Main Profile Bitų greičio kontrolė CBR,VBR Scalable Video Coding (SVC) H.264 and H.265 encoding Region of Interest (ROI) 1 fixed region for main stream Garsas Garso tipas Mono sound Garso suspaudimas G.711/G.722.1/G.726/MP2L2/PCM/AAC-LC Garso bitų greitis 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC) Garso atrankos dažnis 8 kHz/16 kHz Pašalinių garsų šalinimas Yes Internetas Protokolai IPv4，IPv6，TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IGMP, UDP, QoS, FTP, SMTP, UPnP Tiesioginis vaizdo žiūrėjimas Up to 6 channels API Open Network Video Interface (Profile S, Profile T, Profile G (only -F model supports)),ISAPI,SDK User/Host Up to 32 users
3 user levels: administrator, operator, and user
Saugumas Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address) Klientas iVMS-4200,Hik-Connect Naršyklė Plug-in required live view: IE 10, IE 11,
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
Nuotrauka Nuotraukos nustatymai Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser Diena/Naktis režimas Day,Night,Auto,Schedule Wide Dynamic Range (WDR) 120 dB SNR ≥ 52 dB Nuotraukų pagražinimas BLC,HLC,3D DNR Privatumo kaukė 4 programmable polygon privacy masks Sąsaja Interneto sąsaja 1 RJ45 10 M/100 M self-adaptive Ethernet port Vidinė atmintis -F: Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB Įmontuotas mikrofonas Yes,1 built-in microphone Perkrovimo mygtukas -F: Yes Funkcijos Pagrindinės funckcijos Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception Sąsaja Upload to memory card (-F model supports), trigger recording(-F model supports), upload to FTP,notify surveillance center,send email,trigger capture,notify surveillance center,send email,trigger capture Pagrindinis Sistemos parametrai 12 VDC ± 25%, 0.57 A, max. 6.8 W,Ø5.5 mm coaxial power plug,reverse polarity protection,
PoE: IEEE 802.3af, Class 3, max. 8.3 W
Medžiaga Front cover: metal, body: plastic, bracket: plastic Dydis 81 mm × 83.7 mm × 201.96 mm (3.17" × 3.29" × 7.95") Pakuotės dydis 150 mm × 150 mm × 141 mm (5.91" × 5.91" × 5.55") Svoris Approx. 550 g (1.2 lb.) Svoris su įpakavimu Approx. 800 g (1.8 lb.) Sandėliavimo sąlygos -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) Darbo sąlygos -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) Kalba English, Ukrainian Pagrindinės funkcijos Heartbeat,anti-banding,mirror,password protection,password reset via email Patvirtinimai EMC CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021,
RCM: AS/NZS CISPR 32: 2015,
IC: ICES-003: Issue 7
Saugumas
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017,
BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005
Aplinkosauga CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006
Apsauga IP67: IEC 60529-2013
Kodas
KIP2CD1T47G2HLIUFF4
