Kamera Sensorius 1/1.8" Progressive Scan CMOS Maks. rezoliucija 2560 × 2560 Min. apšvietimas Color: 0.01 Lux @ (F2.25, AGC ON),B/W: 0.005 Lux @ (F2.25, AGC ON),B/W: 0 Lux with IR Užrakto greitis 1 s to 1/100,000 s Day & Night IR cut filter Lęšis Lęšio tipas Fixed focal lens, 1.16 mm Focal Length & FOV 1.16 mm, horizontal FOV 180°, vertical FOV 180° Rainelės tipas Fixed Diafragama F2.25 Ryškumo gylis 0.2 m to ∞ DORI DORI D: 23.2 m
O: 9.2 m
R: 4.6 m
I: 2.3 m
Apšvietimas Papildomo apšviešimo tipas IR Papildomo apšvietimo diapazonas Up to 15 m Supplement Light Number 3 IR bangos ilgis 850 nm Išmanus papildomas apšvietimas Yes HEOP Open Resources Memory: 60 MB,
Smart RAM: 800 MB,
eMMC: 2 GB
Computing Power 2 TOPS Open Capability HEOP 2.0 OpendevSDK Deep Learning Structure Caffe,TensorFlow,PyTorch Programming Language C,C++ Vaizdas Pagrindinis srautas 50 Hz: 25 fps/60 Hz: 30 fps:
Fisheye View:
2560 × 2560, 2048 × 2048, 1280 × 1280
180 Panorama View:
2048 × 1536, 1920 × 1440
180 Dual Channel Panorama View:
2048 × 768, 1920 × 720
Panorama View:
2048 × 1536, 1920 × 1440
4PTZ View:
camera 01/camera 02/camera 03/camera 04: 1024 × 768
Fisheye + 3PTZ View:
camera 01: 2048 × 2048, 1024 × 1024
camera 02/camera 03/camera 04: 1024 × 768
4PTZ Fusion View:
2048 × 1536, 1600 × 1200
Antrinis srautas 50 Hz: 25 fps/60 Hz: 30 fps:
Fisheye View:
720 × 720, 480 × 480
180 Panorama View:
640 × 480, 320 × 240
180 Dual Channel Panorama View:
640 × 480, 320 × 240
Panorama View:
640 × 360, 320 × 240
4PTZ View:
camera 01/camera 02/camera 03/camera 04: 640 × 480, 320 × 240
Fisheye + 3PTZ View:
camera 01: 720 × 720
camera 02/camera 03/camera 04: 640 × 480, 320 × 240
Vaizdo suspaudimas Main stream: H.265+/H.265/H.264+/ H.264,
Sub-stream: H.265/H.264/MJPEG
Vaizdo bitų greitis 32 Kbps to 16 Mbps H.264 tipas Baseline Profile,Main Profile,High Profile H.265 tipas Main Profile Bitų greičio kontrolė CBR,VBR Scalable Video Coding (SVC) H.264 and H.265 encoding Region of Interest (ROI) 4 fixed regions for each stream Fisheye rodymas Montavimo tipas Support wall/table/ceiling mounting Decoding Mode Support hardware decoding and software decoding Display Mode 20 display modes in total,
Software decoding: fisheye view, 180 panorama view, 360 panorama view, 360 panorama + PTZ, 360 panorama + 3PTZ, 360 panorama + 6PTZ, 360 panorama + 8PTZ, 2PTZ, 4PTZ, fisheye + 3PTZ, fisheye + 8PTZ, hemisphere, AR hemisphere, cylinder,
Hardware decoding: fisheye view, 180 panorama view, 180 dual channel panorama, panorama view, 4PTZ, fisheye + 3PTZ, 4PTZ fusion
Garsas Garso suspaudimas G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC Garso bitų greitis 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) Garso atrankos dažnis 8 kHz/16 kHz/32 kHz/48 kHz Pašalinių garsų šalinimas Yes Internetas Protokolai TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, ISUP, ARP, WebSocket, WebSockets, SIP Tiesioginis vaizdo žiūrėjimas Up to 20 channels API Open Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP,
Support for Session Initiation Protocol (SIP) for integration with Voice over IP (VoIP) systems, peer to peer or integrated with SIP/PBX
User/Host Up to 32 users
3 user levels: administrator, operator, and user
Saugumas Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.2, host authentication (MAC address) Vidinė atmintis NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),
Together with high-end Hikvision memory card, memory card encryption and health detection are supported.
Klientas iVMS-4200,iVMS-4500,iVMS-5200,Hik-Connect Naršyklė Plug-in required live view: IE 10, IE 11,
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Safari 11+,
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+
Nuotrauka Nuotraukos parametrų keitiklis Yes Nuotraukos nustatymai saturation,brightness,contrast,sharpness,white balance,AGC,adjustable by client software or web browser Diena/Naktis režimas Day,Night,Auto,Schedule,Alarm Trigger Wide Dynamic Range (WDR) Digital WDR Nuotraukų pagražinimas BLC,HLC,3D DNR,Distortion Correction,Defog Privatumo kaukė 8 programmable polygon privacy masks Nuotraukos perdanga LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format. Sąsaja Interneto sąsaja 1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port Vidinė atmintis Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB Įmontuotas mikrofonas Yes, 4 built-in microphones Įmontuotas garsiakalbis Yes, 1 built-in speaker Garsas 1 input (line in), 3.5 mm connector, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium,
1 output (line out), 3.5 mm connector, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium
Signalizacija 2 inputs, 2 outputs (max. 24 VDC, 1 A) RS-485 1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive) Perkrovimo mygtukas 1 Reset Key Funkcijos Pagrindinės funckcijos Motion detection,video tampering alarm,alarm input and output,exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error) Išmaniosios funkcijos Line crossing detection, intrusion detection, region entrance detection, region exiting detection, scene change detection,audio exception detection,defocus detection, unattended baggage detection,object removal detection Sąsaja Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture Išmaniosios funkcijos People Counting Counts people entering, exiting and passing by separately (The data is stored in the flash.)
Supports real-time uploading and uploading by statistic cycle
Sends email reports on daily, weekly, monthly or annually basis
Supports up to 3 detection regions, and independent arming schedule and linkage method
Queue Management Supports up to 8 detection regions, and independent arming schedule and linkage method
Supports 2 detection modes: regional people queuing-up, waiting time detection
Generates reports to compare the efficiency of different queuing-ups and display the changing status of one queue
Supports raw data export for further analysis
Supports real-time data uploading and scheduled data uploading
Regional people queuing-up: supports 4 alarm trigger conditions, including greater than threshold, less than threshold, equal to threshold, not equal to threshold
Waiting time detection: supports 1 alarm trigger condition, including greater than threshold
Heat Map A graphic description of visits (by calculating amount of people or amount of dwell time) in a configured area.,
Two report types are available, space heat map and time heat map line chart.
Intersection Analysis Detects and analyze flow in an intersection-like scene, and generate reports
Support one intersection of up to 10 ways
Pagrindinis Sistemos parametrai 12 VDC ± 20%, 1 A, max. 11.5 W,two-core terminal block,
PoE: IEEE 802.3af, Class 3, max. 12.5 W
Medžiaga Metal Dydis Ø140.3 mm × 59.4 mm (Ø5.5" × 2.3") Pakuotės dydis 260 mm × 230 mm × 135 mm (10.2" × 9.1" × 5.3") Svoris Approx. 715 g (1.58 lb.) Svoris su įpakavimu Approx. 1206 g (2.66 lb.) Sandėliavimo sąlygos -40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing) Darbo sąlygos -40 °C to 60 °C (-40 °F to 140 °F). Humidity 95% or less (non-condensing) Kalba 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian Pagrindinės funkcijos Heartbeat,flash log,password reset via email,password protection,one-key reset,anti-banding Šildytuvas Yes Cable Length 0.31 m (1.02 ft.) Patvirtinimai EMC CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021, EN 50121-4: 2016+A1:2019,
RCM: AS/NZS CISPR 32: 2015,
IC: ICES-003: Issue 7,
KC: KN32: 2015, KN35: 2015
Saugumas UL: UL 62368-1,
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017,
BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005
Aplinkosauga CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006
Apsauga IP67: IEC 60529-2013,IK10: IEC 62262:2002
Kodas
KIPDS2CD6365G1IVS116
