Kamera Sensorius 1/2.8" progressive scan CMOS Maks. rezoliucija 2560 × 1440 Min. apšvietimas Color: 0.005 Lux @(F1.5, AGC ON); B/W: 0.001 Lux @(F1.5, AGC ON); 0 Lux with IR Užrakto greitis 1 to 1/30,000 s Day & Night IR cut filter Priartinimas 4 × optical, 16 × digital Lęšis FOV 2.8 to 12 mm FOV Horizontal field of view: 96.7° to 31.6° (wide-tele)
Vertical field of view: 51.1° to 17.7° (wide-tele)
Diagonal field of view: 115.1° to 36.3° (wide-tele)
Fokusavimas Auto, semi-auto, manual Diafragama Max. F1.5 Priartinimo greitis Approx. 2 s (optical lens, wide-tele) Apšvietimas Papildomo apšvietimo diapazonas IR distance: up to 50 m, white light distance: up to 6 m Išmanus papildomas apšvietimas Yes PTZ Movement Range (Pan) 0° to 350° Movement Range (Tilt) 0° to 90° Pan greitis Configurable, from 0.1°/s to 60°/s. Preset speed: 60°/s Tilt greitis Configurable, from 0.1°/s to 50°/s. Preset speed: 50°/s Proporcingas Pan Yes Iš anksto išsaugoti nustatymai 300 Išsaugotų nustatymų sustabdymas Yes Patruliavimas 8 patrols, up to 32 presets for each patrol Park Action Preset,Patrol Scan 3D pozicija Yes PTZ būsenos vaizdavimas Yes Užduočių grafikas Preset,Patrol Scan,dome reboot, dome adjust, aux output Išjungimo atmintis Yes Vaizdas Pagrindinis srautas 50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)
60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)
Antrinis srautas 50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)
Trečias srautas 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
Vaizdo suspaudimas Main Stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264/MJPEG
Third Stream: H.265/H.264/MJPEG
Vaizdo bitų greitis 32 Kbps to 16 Mbps H.264 tipas Baseline profile/main profile/high profile H.265 tipas Main profile Scalable Video Coding (SVC) H.264 and H.265 encoding Region of Interest (ROI) 8 fixed regions for each stream Garsas Garso suspaudimas G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM Garso bitų greitis 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 Kbps to 160 Kbps(MP2L2) Internetas Protokolai IPv4/IPv6, HTTP, HTTPS, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, DHCP, PPPoE, Bonjour Tiesioginis vaizdo žiūrėjimas Up to 20 channels API Open Network Video Interface, ISAPI, SDK, ISUP User/Host Up to 32 users. 3 user levels, administrator, operator and user Saugumas Password protection, complicated password, HTTPS encryption, watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.2, host authentication (MAC address) Vidinė atmintis NAS (NFS, SMB/CIFS), auto network replenishment (ANR) Klientas iVMS-4200, HikCentral, Hik-Connect
*Wi-Fi connection with Hik-Connect directly is not possible.
Naršyklė IE10-11, Chrome 57.0+, Firefox 52.0+, Safari 12+ Wireless (Wi-Fi) Šifravimo režimas 64/128-bit WEP,WPA/WPA2,WPS Wi-Fi protokolai IEEE802.11b, 802.11g, 802.11n Dažnio diapazonas 2.4 GHz - 2.4835 GHz Kanalo dažnių juostos plotis 20/40MHz Moduliacija 802.11b: CCK, DQPSK, DBPSK
802.11g: OFDM/64-QAM, 16-QAM, QPSK, BPSK
802.11n: OFDM/64-QAM, 16-QAM, QPSK, BPSK
Perdavimo greitis 802.11b: 11, 5.5, 2, 1 Mbps
802.11g: 54, 48, 36, 24, 18, 12, 9, 6 Mbps
802.11n: mcs0 - msc7
Belaidžio ryšio diapazonas Up to 150 m (The performance varies based on actual environment) Antenna Built-in 2 antennas Nuotrauka Nuotraukos nustatymai Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser Wide Dynamic Range (WDR) 120 dB Rūko šalinimas Digital defog Nuotraukų pagražinimas BLC, HLC, 3D DNR Privatumo kaukė 24 programmable polygon privacy masks, mask color configurable Regioninis fokusavimas Yes Regioninė ekspozicija Yes Sąsaja Interneto sąsaja 1 RJ45 10M/100M self-adaptive Ethernet port Saugyklos vieta Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB Įmontuotas mikrofonas 1 built-in microphone Įmontuotas garsiakalbis 1 built-in speaker, 8 Ω, 2 W. Max sound pressure level: 100 dB (10 cm) Garsas 1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%; 1 output (line out), line level, output impedance: 600 Ω Signalizacija 1 input, 1 output Galia 12 VDC, max. 60 mA Funkcijos Pagrindinės funkcijos Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error), alarm input and output Išmaniosios funkcijos Face detection, line crossing detection, intrusion detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, audio exception detection Signalizacijos sąsaja Preset, Patrol Scan，Upload to FTP/memory card/NAS, notify surveillance center, send email, audible warning，Flashing Alarm Išmaniosios funkcijos Multi-Target-Type Detection Supports simultaneous detection and capture of human body, face and vehicle Pagrindinis Sistemos parametrai 12 VDC, 3.33 A & PoE (802.3at), 42.5 to 57 VDC, 0.6 A
Max. 16 W (including max. 2.4 W for IR, 1.2 W for white light flashing)
Dydis 179.3 mm × 120.5 mm × 182 mm (7.06" × 4.74" × 7.17") Svoris Approx. 1.125 kg (2.48 lb.) Medžiaga ADC12 + PC Darbo sąlygos -30 °C to 65 °C (-22 °F to 149 °F). Humidity 90% or less (non-condensing) Patvirtinimai Apsauga IP66 (IEC 60529-2013), TVS 6000V lightning protection, surge protection and voltage transient protection
Kodas
KIPSPDS2DE3A404IWGEW
